Directshow filters SDK
Directshow filters SDK for WindowsThe Directshow filters SDK allows seamless integration of native capture and rendering devices under Windows.
The SDK is based on standard Directshow interfaces and on additional COM interfaces for Deltacast cards specific features configuration.
Specifications
Directshow filters SDK features
| Capture filters features | SDI, DVI-D, DVI-A, HDMI video capture SDI audio de-embedding VBI lines capture 3G SDI video format support : 1080p 50, 59.94 and 60 fps HD SDI video formats: 1080p 23.98, 24, 25, 29.97 and 30 fps, 1080i 25, 29.97 and 30 fps, 720p 50, 59.94 and 60 fps SD SDI video formats: PAL, NTSC DVI graphics formats up to 2560x1600 HDMI video formats up to 1080p Multi-channel, multi-card operation Black frames generation in case of input signal loss Push-mode filters Specific operating modes optimized for file operations or for real-time applications Property pages for configuration and monitoring Proprietary COM interface for advanced programming configuration |
Directshow filters SDK features
| Transmission filters features | SDI video streaming SDI audio embedding 3G SDI video format support : 1080p 50, 59.94 and 60 fps HD SDI video formats: 1080p 23.98, 24, 25, 29.97 and 30 fps, 1080i 25, 29.97 and 30 fps, 720p 50, 59.94 and 60 fps SD SDI video formats: PAL, NTSC Transmission genlock on SDI input or on analog BlackBurst reference Specific operating modes optimized for file operations or for real-time applications Property pages for configuration and monitoring Proprietary COM interface for advanced programming configuration |
