DELTA-3G-elp 10
Compact single channel SDI capture cardThis product you are looking for is no longer recommended for new design, please contact us to find the best alternative.
Still some questions, looking for specific technical documentation or any other inquiry?
Please do contact us, we’re here to help you!
- 3G SDI
-
THUNDER-
BOLT - SCALER
- PCIe 2
-
LOW-
PROFILE
Specifications
Hardware features
| Bus Interface | PCIe Gen2 x4 |
| Form Factor | Low-profile, half-length PCIe |
| Connectors | BNC |
| Sync Input | No |
| Serial numbering | 64-bit unique ID per card |
| LTC Input | Support of LTC companion card for Analog LTC (ST12-1) capture (on request only, ask support) |
Hardware Processing
| Video Signal Modes | Single-link 4:2:2 10-bit |
| Scalers | 1x thumbnail scaler |
| CSC | No |
Video Interfaces
| Video Interfaces |
3Gbps SDI (ST 424) Level A and Level B-DL (ST 425-1),
HD-SDI (ST 292), SD-SDI (ST 259) |
| Video Formats |
SD : 625i50 (PAL), 525i59.94 (NTSC)
HD 1280x720 : 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24 ,720p23.98 HD 1920x1080 : 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080p60, 1080p59.94, 1080p50. 2K 2048x1080 : 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080p60, 1080p59.94, 1080p50, 1080p48, 1080p47.952 |
| Audio formats | Embedding or de-embedding of up to 16 digital audio channels per HD-SDI link or up to 32 digital audio channels per 3G-SDI link. (ST 272M and ST 299-x) |
| Ancillary data | ST 291, ST 272/299 (Audio), ST 12-2 (VITC), ST 352 (payload ID), ST 334 (closed captions) |
